flamex® Series

Protected from flying sparks

flamex hybrid® -a- Flame-resistant special tubing for gaseous media

Whether used near welding systems or grinding machines: flamex® special tubing made of halogen-free polyurethane (PUR) ensures optimal resistance to weld spatter and flying sparks.
With the hybrid series, we have consistently developed our Flamex series in order to offer even further innovation at all levels – from flexibility to sustainability. The flamex hybrid® -a- (air) is our special tubing for all applications with gaseous media.

Flexible special tubing for pressurized-air applications & gaseous media

tooltip text
\

Special tubing for pressurized-air applications & gaseous media

\

Polyurethane pneumatic tubing

\

Air - for gaseous media

Our hybrid series of halogen-free flame-resistant special tubing combines the durability and strength of our well-known flamex® series with innovative features for the respective area of application. Accordingly, flamex hybrid® -a- pneumatic tubing provides you with reliable, tried-and-tested quality with the bonus of application-specific properties: good material flexibility for smaller bending radii and further improved dynamic range of the pressure resistance from -0.9 – 16 bar, depending on the temperature. Both development and production take place in Germany under the highest quality standards in accordance with a DIN EN ISO 9001-certified quality management system.

Polyurethane pneumatic tubing with proven safety - implemented sustainably

The flamex hybrid® -a- pneumatic tubing material is self-extinguishing in the event of a fire and ensures proven protection against welding spatter and flying sparks, tested by the Underwriters Laboratories independent testing institute according to the UL 94 V2 to V0 classification. In order to support the sustainability strategies of many companies, our flamex hybrid® special tubing for gaseous media is completely recyclable.

Note relating to Papurex cost efficiency: The flamex hybrid® -a- reduces operating costs due to a long service life and significantly longer maintenance intervals compared to most conventional pneumatic tubing.

flamex hybrid® -a- Special flame-resistant polyurethane tubing overview

\
Tremendous resistance to flying sparks and weld spatter
\
Appreciably longer maintenance intervals and a long service life
\
Halogen-free, flame-resistant special tubing that is self-extinguishing in the event of a fire
\
Tested by Underwriters Laboratories (UL 94 V2 to V0 classification)
\
Fast, easy and inexpensive installation
\
Fits all standard plug-in connections made of metal or suitable screwed connections made of plastic
\
Resistant to hydrolysis
\
Resistant to microbes
\
Resistant to many cleaning agents, chemicals, solvents and other contact agents
\
Very tight bend radii possible
\
Good UV-resistance
\
Maximum abrasion and chafing resistance (suitable for drag-chains)
\
LABS-free (free from substances inhibiting paint adhesion)
\
Suitable for vacuum applications
\
100% recyclable
\
Approved for use in the international automotive industry

More about flamex hybrid® -a- special tubing?

Do you have further questions about flamex hybrid® -a- special polyurethane tubing for gaseous media?
Do not hesitate to contact us – we are happy to advise you.
