flamex® Series

Protected from flying sparks

flamex hybrid® -w- Polyurethane special tubing for liquid media

For years, flamex® special tubing has stood for the highest quality and reliability in terms of protection against weld spatter and flying sparks.

With the flamex hybrid® series of special polyurethane tubing, our developers have gone a step further to make additional optimizations for the media conveyed. In this case, the suffix -w- literally stands for water and characterizes our special liquid media tubing – suitable for use under the toughest industrial conditions.

Extremely flexible Special tubing made of flame-resistant polyurethane (PUR)

tooltip text
\

special tubing made of flame-resistant polyurethane (PUR)

\

Enormous resistance in difficult working environments

\

Water - Special tubing for liquid media

As a perfect addition to the flamex hybrid® series, our special tubing for water and other liquid media impresses users with its enormous resistance in difficult working environments. The tubing is made of halogen-free polyurethane and provides reliable protection against weld spatter near welding systems and against flying sparks from grinding machines. In the event of a fire, the material is self-extinguishing, which further increases workplace safety in industry or trade. We were also able to bring the flexibility of our tubing to a new level and raise the bending capacity almost to the level of rubber. All tubing is developed and manufactured in Germany in accordance with DIN EN ISO 9001 quality management.

Polyurethane special tubing for a wide range of applications

With an operating pressure of 8 bar up to 90 °C, the flamex hybrid® -w- special polyurethane tubing covers a wide range of applications – for water as well as for many other liquid media. Our special tubing is available by the meter in various configurations, for example on rolls of 5 meters or more. As part of our standard range, red and green polyurethane tubing with the dimensions 6.00 mm, 8.00 mm, 10.00 mm and 11.00 mm DN is available on a permanent basis – we are happy to produce other sizes and colors on request.

Easy handling: flamex® hybrid -w- tubing fits all standard plug-in connections made of metal or suitable screwed connections made of plastic. Installation is fast, easy and inexpensive. The tubing is 100% recyclable.

flamex hybrid® -w- Special polyurethane tubing overview

\
Very good protection against flying sparks and weld spatter
\
Optimized flow; up to 10% more flow compared to conventional tubing
\
Long service life with extended maintenance intervals
\
Halogen-free and self-extinguishing in the event of a fire
\
Classified from UL 94 V2 to V0 by Underwriters Laboratories Inc.®
\
Fast, easy and inexpensive installation
\
Fits all standard plug-in connections made of metal or suitable screwed connections made of plastic
\
Resistant to hydrolysis (suitable for applications with or in water)
\
Resistant to microbes
\
Resistant to many cleaning agents, solvents, chemicals and other contact agents
\
Very flexible with tight bending radii
\
UV-resistant
\
Maximum abrasion and chafing resistance (suitable for drag-chains)
\
Free from substances inhibiting paint adhesion (LABS-free)
\
Suitable for vacuum applications
\
100% recyclable
\
Approved for use in the international automotive industry

More about flamex hybrid® -w- special tubing?

We are happy to manufacture our flamex® hybrid -w- polyurethane special tubing in your desired dimensions or color.
Do not hesitate to contact us for personal advice – we are happy to advise you.
